: Zone-2, Increased Safety Type "e" & Restricted
Breathing Type as per
: Zone 1, gases & vapours of Group I, IIA,& IIB as per IS :2148-81
Protection : IP-55 as per IS : 2147 - 62
Certificate : C.M.R.S no. CMRS/TC/1247 dated 16/9/93
Material : AL alloy LM-6, CI on request
Terminals : Stud type of suitable size
Earthing : One each internal & external
Wiring : PVC insulated copper conductor of suitable ratings
Labels : Label & Tag Plate provided as required
Mounting : Suitable for wall or structure mounting on bracket having drilled hole
Paint : Epoxy powder coated of shade 631 externally or as required.
Cable Entry : 2 nos. Entries of 3/4*ET.
Thread Forms : Std threads will be ET / BS Con. Other threads like NPT/BSP , ISO, PG equivalent made on request.
